BLOWFISH
Modular LED High & Low Bay Lighting
25W - 595W
3 210lm - 81 693lm
Blowfish Overview
The Blowfish is a modular industrial LED high-bay and low-bay lighting platform engineered for warehouses, industrial plants, distribution centres, hangars, cold-storage facilities, manufacturing areas and other large indoor spaces. Its broad range of outputs allows the same platform to support lower mounting applications through to high-volume industrial environments requiring substantially higher light output.
Blowfish Low-Bay configurations range from 25 W to 187 W with outputs up to 22,031 lm, while High-Bay configurations range from 57 W to 595 W with outputs up to 81,693 lm. Multiple precision optical distributions allow the light pattern to be selected according to mounting height, aisle geometry and working area rather than relying on one general-purpose beam.
The extruded aluminium construction combines effective thermal management with a lightweight modular form. Individual fixtures can also be joined lengthways or side-by-side using purpose-built brackets, allowing the lighting system to be scaled according to project requirements. IP65 ingress protection, IK10 impact resistance and optional intelligent controls provide additional flexibility for demanding industrial installations.
Key Benefits
-
One Platform for Low-Bay & High-Bay Lighting
-
Precision Optical Control
-
Modular & Scalable Construction
-
High-Efficiency LED Performance
-
Industrial Protection
Specifications
-
25W (300mm)
-
37W (300mm)
-
50W (600mm)
-
75W (600mm)
-
75W (900mm)
-
112W (900mm)
-
100W (1200mm)
-
150W (1200mm)
-
125W (1500mm)
-
187W (1500mm)
-
-
25W (300mm) - 3,210lm
-
37W (300mm) - 4,406lm
-
50W (600mm) - 6,421lm
-
75W (600mm) - 8,812lm
-
75W (900mm) - 9,631lm
-
112W (900mm) - 13,219lm
-
100W (1200mm) - 12,842lm
-
150W (1200mm) - 17,625lm
-
125W (1500mm) - 16,052lm
-
187W (1500mm) - 22,031lm
-
-
25W (300mm) - 128lm/w
-
37W (300mm) - 117lm/w
-
50W (600mm) - 128lm/w
-
75W (600mm) - 117lm/w
-
75W (900mm) - 128lm/w
-
112W (900mm) - 117lm/w
-
100W (1200mm) - 128lm/w
-
150W (1200mm) - 117lm/w
-
125W (1500mm) - 128lm/w
-
187W (1500mm) - 117lm/w
-
-
4 m – 15 m
-
-
57W (300mm)
-
66W (300mm)
-
115W (600mm)
-
132W (600mm)
-
172W (900mm)
-
198W (900mm)
-
230W (1200mm)
-
264W (2x600mm)
-
264W (1200mm)
-
287W (1500mm)
-
397W (2x900mm)
-
595W (3x900mm)
-
-
57W (300mm) - 9,378lm
-
66W (300mm) - 9,378lm
-
115W (600mm) - 18,755lm
-
132W (600mm) - 18,755lm
-
172W (900mm) - 28,133lm
-
198W (900mm) - 28,133lm
-
230W (1200mm) - 37,510lm
-
264W (2x600mm) - 37,510lm
-
264W (1200mm) - 37,510lm
-
287W (1500mm) - 46,888lm
-
397W (2x900mm) - 56,265lm
-
595W (3x900mm) - 81,693lm
-
-
57W (300mm) - 163lm/w
-
66W (300mm) - 141lm/w
-
115W (600mm) - 163lm/w
-
132W (600mm) - 141lm/w
-
172W (900mm) - 163lm/w
-
198W (900mm) - 141lm/w
-
230W (1200mm) - 163lm/w
-
264W (2x600mm) - 141lm/w
-
264W (1200mm) - 163lm/w
-
287W (1500mm) - 141lm/w
-
397W (2x900mm) - 163lm/w
-
595W (3x900mm) - 137lm/w
-
-
4 m – 25 m
-
-
4000K Standard
-
3000K / 5000K / 6500K Optional
-
-
>70
-
-
L80B10 - 50 000 Hours
-
-
198–264 V AC
-
-
-20°C to 60°C
-
-
10kV (Standard)
-
20kV (Optional)
-
-
IP65
-
-
IK10
-
-
SABS Approved
-
-
Polycarbonate - IK10
-
-
Marine Grade Aluminium
-
-
Output Power: 5W (Standard) | 20W (Optional)
-
Emergency Duration: >1HR
-
-
30° Narrow Beam
-
60° Medium Beam
-
90° Wide Beam
-
Asymmetrical Distribution
-
Symmetrical Wide Distribution
-
Applications
-
Industrial plant lighting
-
Warehouse lighting
-
Distribution centre lighting
-
Manufacturing facility lighting
-
Cold-storage lighting
-
Hangar lighting
-
Workshop lighting
-
High-volume industrial spaces
-
High-rack warehouse lighting
-
Hazardous-area lighting – certified configurations where applicable
