MAGFLOOD floodlight

MAGFLOOD
Industrial LED Floodlight

200W - 600W

27 940lm - 74 902lm

MAGFLOOD Overview

The MAGFLOOD is a high-output industrial LED floodlight engineered for mines, processing plants, yards, security areas and other large outdoor applications. Available from 200 W to 600 W with outputs up to 74,902 lm, it combines marine-grade aluminium construction, IP66 protection and efficient thermal management for demanding operating environments.

​

Multiple optical distributions, including symmetrical and asymmetrical options, allow light to be directed according to mounting height, area geometry and project requirements while helping control spill light and unnecessary uplight. For corrosive environments such as coastal facilities and chemical plants, optional 316 stainless steel bracketry and driver-box components provide additional corrosion resistance.

Key Benefits

  • Precision optical control — 30°, 60°, 90°, T4 asymmetric, FT asymmetric and general flood distributions support application-specific lighting design.

  • High-output performance — 200 W to 600 W configurations deliver up to 74,902 lm for large industrial and outdoor areas.

  • Built for demanding environments — marine-grade aluminium construction and IP66 protection support operation in dusty, wet and exposed locations.

  • Corrosion-resistant options — optional 316 stainless steel bracketry and driver components are available for coastal and chemically aggressive environments.

Specifications

    • 200W (Single)

    • 300W (Single)

    • 400W (Double)

    • 600W (Double)

    • 200W - 27,940lm

    • 300W - 37,451lm

    • 400W - 55,880lm

    • 600W - 74,902lm

    • 200W - 174lm/w

    • 300W - 163lm/w

    • 400W - 174lm/w

    • 600W - 163lm/w

    • 4000K Standard

    • 2200K / 3000K / 5000K / 6500K Optional

    • L90B10 - 100 000 Hours

    • >70

    • 220V - 240V (Standard)

    • 90V - 305V (Optional)

    • -40°C to 55°C

    • 10kV (Standard)

    • 20kV (Optional)

    • IP66

    • IK09

    • SABS Approved

    • Tempered Glass - IK08 (Standard)

    • Polycarbonate - IK10 (Optional)

    • Marine Grade Aluminium

    • HDG Floodlight Mounting Bracket (Standard)

    • 316 Stainless Steel Floodlight Mounting Bracket & Driver Box (Optional)

    • No

Applications

  • Industrial lighting

  • Outdoor lighting

  • Security lighting

  • Dusty & dirty environments

  • Plant lighting
